Main Features

• Added filter reactor for softer arc,quieter molten pool,less spatter,and more stable welding

• Open circuit voltage up to 80V, suitable for long cable construction sites

• IP23S protection level, can withstand hot rain at±60° from vertical, more adaptable to outdoorwork, higher safety

• Independent thrust and arc ignition current adjustment

• Optional generator set for generator power supply

• Overheat and undervoltage protection

Applications

• Mainly suitable for Ø≤6.0mm acid, alkaline electrodes, and manual TIGwelding for carbon steel, alloy steel, stainless steel, cast iron, etc.

• Widely used in steel structures,pressure vessel manufacturing ,mechanical manufacturing, pipeline installation, equipment repair and etc.
