Application

• Primarily used for weld root cleaning, groove preparation, defect removal, and casting finishing on carbon steel, low-alloy steel, stainless steel, cast iron, aluminum alloys, and copper alloys;

• Widely applied in industrial equipment installation, power construction, chemical engineering, oilfield development, building construction, shipbuilding, machinery manufacturing, and pressure vessel fabrication;

Main Features

• High no-load voltage with output current up to 1000/1250A, enabling efficient metal gouging;

• 80kHz output frequency ensures stable current and uniform gouging performance;

• 100% duty cycle at 40°C ambient temperature, ideal for continuous heavy-duty operations;

• 32% smaller footprint reduces workspace requirements;

• Independent adjustment of arc ignition current and thrust current caters to diverse welding preferences;

• Superior SMAW stability with minimal spatter and quiet molten pool, compatible with acid and basic electrodes of all specifications;

• Intuitive control panel with easy parameter adjustment, optimized for operator convenience;

• Customizable remote control function enhances operational efficiency.
